notifier b501 plug-in detector base

Description

notifier b501 plug-in detector base key features and specifications
n

n
• Compatibility: Works with a variety of Notifier plug-in detectors, including smoke, heat, and multi-criteria sensors.

n

• Mounting: A low-profile, 4-inch diameter base designed to mount to standard electrical boxes (4-inch square or 3.5-inch octagonal) and other mounting centers.

n

• Wiring: Features SEMS screws for easy wiring connections and supports wire gauges from 24 to 12 AWG.

n

• Power and communication: Provides secure electrical contacts for both power and communication between the detector and the control panel. Communication occurs over the power lines.

n

• System integration: Intended for intelligent systems that have screw terminals for power (+ and -) and remote annunciator connections.

n

• Ease of use: The plug-in system allows for quick and easy installation and replacement of the detector head.

n

• Tamper-resist feature: Includes a tamper-resist feature to prevent unauthorized removal of the detector head.

n

• Operating voltage:  15 to 32 VDC.

n

• Standby current: 150A to 24VDC
