Hammer CPS6002 Dual Zone Electric Fence Energizer

Description

Hammer CPS6002 Dual Zone Electric Fence Energizer key features:
n
nDual high-voltage zones
n
nThe CPS6002 has two separate, hard-wired zones, each with its own high-voltage transformer. If one zone is shorted, the other zone remains powered and operational, ensuring continuous security.
n
nSmartlink anti-tampering technology
n
n The energizer includes a proprietary feature called Smartlink, which monitors the earth return wire. This prevents intruders from bypassing the alarm system by bridging the high-voltage output and return wires.
n
nComprehensive monitoring with alarms:
n
nThe system monitors several aspects of the fence’s security, including:
n

n
• n
  n
  • High-voltage live line: Triggers an alarm if the voltage is tampered with or an abnormal level is detected.

  n

  • Earth line: Monitored via the Smartlink feature to detect tampering.

  n

  • Gate (auxiliary): An alarm is triggered if a gate is opened.

  n

  n

n

nProgrammable LCD keypad
n
nA user-friendly LCD keypad is included for programming, controlling, and monitoring the system. Multiple keypads can be added for large installations.
n
nBuilt-in battery backup
n
n A 7Ah backup battery is included, providing up to 12 hours of operation during a power outage. The unit is also solar-enabled.
n
nPower protection
n
nBuilt-in lightning and power surge suppression protects the energizer from electrical disturbances.
n

n

n

n

Hammer CPS6002 Dual Zone Electric Fence Energizer has the following technical specifications:

n

n
• Zones: 2 (dual high voltage)

n

• Output energy: 4 joules per zone

n

• Stored energy: 15 joules total

n

• Backup time: Up to 12 hours

n

• Battery capacity: 7Ah

n

• Control interface: LCD keypad included

n

• Protections: Built-in lightning and surge suppression

n

n

n

n

n
• Connects to an armed response radio.

n

• Connections for a siren and strobe light are included.

n

• Remote control option is available.

n

• Features three-level PIN code operation.

n

• Easy-to-install design
